Lexicon
Tungsten carbide
Grooving horizontal, vertical
Manual feed
Tipped tool
Resharpenable clearance face
Information
| Application: | For cutting different groove widths. |
|---|---|
| Machine: | Spindle moulders, moulders, edgebanding machines and stationary routers with/without CNC control, double-end tenoners. |
| Workpiece material: | Solid wood along grain and across grain; uncoated, coated and veneered wood derived materials in top layer and middle layer. |
| Technical information: | Adjustment of cutting widths with spacers (adjustment 0.10 mm). |
Tool selection
| Id |
D mm |
SB mm |
BO mm |
BOmax mm |
NLA mm |
Z |
V |
NT mm |
n min-1 |
Stock |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
20661
Adjust. grooving cutterset
HW:150x7.5-28x50 |
D:
150
mm
|
SB:
7.5
mm
|
BO:
50
mm
|
BOmax:
50
mm
|
NLA:
mm
|
Z:
4+4
|
V:
4
|
NT:
22
mm
|
n:
5200
min-1
|
Stock:
Stock:
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
20667
Adjust. grooving cutterset
HW:RE,D160,d30,Z2,VSB4-13 |
D:
160
mm
|
SB:
4
mm
|
BO:
30
mm
|
BOmax:
mm
|
NLA:
mm
|
Z:
4
|
V:
4
|
NT:
35
mm
|
n:
5000
min-1
|
Stock:
1
Stock:
available from stock
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
20662
Adjust. grooving cutterset
HW:220x5-30x30,Z12V4 |
D:
220
mm
|
SB:
5
mm
|
BO:
30
mm
|
BOmax:
35
mm
|
NLA:
2/10/60
mm
|
Z:
4+4
|
V:
4
|
NT:
55
mm
|
n:
3500
min-1
|
Stock:
1
Stock:
available from stock
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
-
20661 Adjust. grooving cutterset
HW:150x7.5-28x50D: 150 mmSB: 7.5 mmBO: 50 mmBOmax: 50 mmNLA: mmZ: 4+4V: 4NT: 22 mmn: 5200 min-1Stock:Stock:Request Price -
20667 Adjust. grooving cutterset
HW:RE,D160,d30,Z2,VSB4-13D: 160 mmSB: 4 mmBO: 30 mmBOmax: mmNLA: mmZ: 4V: 4NT: 35 mmn: 5000 min-1Stock: available from stockStock: 1Request Price -
20662 Adjust. grooving cutterset
HW:220x5-30x30,Z12V4D: 220 mmSB: 5 mmBO: 30 mmBOmax: 35 mmNLA: 2/10/60 mmZ: 4+4V: 4NT: 55 mmn: 3500 min-1Stock: available from stockStock: 1Request Price
Explanation of abbreviations
D
Diameter
SB
Cutting width
BO
Bore diameter / interface
BOmax
Maximum bore diameter
NLA
Pinhole dimensions
Z
Number of teeth
V
Number of spurs
NT
Grooving depth
n
RPM
Stock
Stock availability
